How the Two Materials Perform

Weight and Handling

Pre-insulated polyurethane duct board is significantly lighter than galvanised sheet metal, which reduces handling time on site and can lower installation labour on larger runs.

Thermal Performance

Duct board carries its insulation within the material itself, while sheet metal needs separate external wrap or internal lining to reach the same thermal performance.

Acoustic Performance

Duct board's denser core structure tends to attenuate airborne noise more effectively than bare sheet metal, though lined sheet metal can close much of that gap.

Installation Time

Lightweight duct board sections are quicker to cut, join, and fit than sheet metal, which typically needs on-site fabrication support for transitions and custom runs.

Compliance Considerations for Each Material

Both materials need to meet AS 4254 requirements for ductwork on air-handling systems, covering construction, sealing, and pressure class ratings.

Duct board manufacturers publish pressure class limits that need to be checked against project design pressures before specification. Sheet metal has a wider pressure class range and suits higher-pressure systems where duct board reaches its performance ceiling.

Which Projects Suit Which Material

Lightweight Duct for Multi Residential and Refurbishment Projects

Duct board's lighter weight and faster install time suit multi-residential builds and refurbishment projects, where access is often tighter and program timelines are shorter.

Sheet Metal for Large Commercial and High Pressure Systems

Larger commercial systems, higher design pressures, and projects needing custom transitions typically call for sheet metal, particularly where non-standard geometry is involved.

Hybrid Approaches

Some commercial projects use sheet metal for main runs and risers, then transition to lightweight duct for branch runs into individual tenancies or apartments, balancing performance against cost and install time.

Cost and Program Considerations

Material cost is only one part of the comparison. Sheet metal typically costs more per metre than duct board, but the total project cost depends heavily on install time, fabrication needs, and program length.

Labour and Program Impact

Duct board's lighter weight and simpler jointing can reduce install labour on long straight runs, which matters most on projects with tight construction programs.

Fabrication Lead Time

Sheet metal transitions and custom fittings often need fabrication before they reach site, while duct board can sometimes be cut and fitted directly on the job.

Long Term Durability

Sheet metal generally holds up better under repeated physical contact and in service spaces with higher foot traffic, which can offset a higher upfront cost over the life of a system.

Weighing these factors against the project's specific access, program, and design pressure requirements is usually more useful than comparing material cost alone.

Specifying Commercial Ducting Supplies from One Source

Vic Air supplies and fabricates both lightweight duct and sheet metal ductwork from a single source, so contractors don't need to manage two separate suppliers on a project that uses both materials.

For help working out which material suits a specific project, or a mix of both, our HVAC estimation service can provide project-specific guidance and costing before construction begins.

Full technical requirements for both materials are set out in AS 4254.2 Ductwork for Air-Handling Systems, published by Standards Australia.

Frequently Asked Questions

Q. Is lightweight duct board as durable as sheet metal?

Duct board performs well within its specified pressure range, while sheet metal generally offers greater resistance to higher pressures and physical impact, making it more suitable for demanding commercial environments.

Q. Can lightweight duct and sheet metal be used in the same HVAC system?

Yes. Many commercial projects use sheet metal for main duct runs and risers before transitioning to lightweight duct board for branch ducts serving individual tenancies or apartments.

Q. Does lightweight duct board require additional insulation?

No. Duct board incorporates insulation within the material itself. Sheet metal ductwork generally requires separate insulation or internal lining to achieve similar thermal performance.

Q. Which material is quicker to install?

Lightweight duct board is generally faster to cut, join, and install. Sheet metal installations often require additional workshop fabrication and on site fitting for custom sections.

Q. Does Vic Air supply both lightweight duct and sheet metal?

Yes. Vic Air supplies and fabricates both lightweight duct board and sheet metal ductwork, allowing contractors to source complete commercial ducting solutions from one supplier.
